Intel Core i5-12500 processor 18 MB Smart Cache Box
Roll over image to zoom inClick to Open expanded view
Model: BX8071512500
EAN: 5032037238564

Intel Core i5-12500 processor 18 MB Smart Cache Box

Manufacturer:
Intel
Intel Core i5-12500, Intel® Core™ i5, LGA 1700, Intel, i5-12500, 64-bit, 12th gen Intel® Core™ i5
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

    Description

    Intel Core i5-12500. Processor family: Intel® Core™ i5, Processor socket: LGA 1700, Processor manufacturer: Intel. Memory channels: Dual-channel, Maximum internal memory supported by processor: 128 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. On-board graphics card model: Intel UHD Graphics 770, On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1, On-board graphics card base frequency: 300 MHz. Market segment: Desktop, Use conditions: PC/Client/Tablet, Workstation, PCI Express slots version: 5.0, 4.0. Package type: Retail box

    Product Properties

    • Model
    • BX8071512500
    • EAN
    • 5032037238564
    • Features
    • Commodity Classification Automated Tracking System (CCATS)
    • G167599
    • CPU configuration (max)
    • 1
    • Direct Media Interface (DMI) Revision
    • 4.0
    • Embedded options available
    • No
    • Execute Disable Bit
    • Yes
    • Export Control Classification Number (ECCN)
    • 5A992CN3
    • Idle States
    • Yes
    • Market segment
    • Desktop
    • Maximum number of PCI Express lanes
    • 20
    • PCI Express configurations
    • 1x16+1x4, 2x8+1x4
    • PCI Express slots version
    • 5.0, 4.0
    • Scalability
    • 1S
    • Supported instruction sets
    • SSE4.1, SSE4.2, AVX 2.0
    • Thermal Monitoring Technologies
    • Yes
    • Use conditions
    • PC/Client/Tablet, Workstation
    • Graphics
    • Discrete graphics card
    • No
    • Discrete graphics card model
    • Not available
    • Multi-Format Codec Engines
    • 2
    • Number of displays supported (on-board graphics)
    • 4
    • Number of execution units
    • 32
    • On-board graphics card
    • Yes
    • On-board graphics card base frequency
    • 300 MHz
    • On-board graphics card DirectX version
    • 12.0
    • On-board graphics card dynamic frequency (max)
    • 1450 MHz
    • On-board graphics card ID
    • 0x4690
    • On-board graphics card maximum resolution (DisplayPort)
    • 7680 x 4320 pixels
    • On-board graphics card maximum resolution (eDP - Integrated Flat Panel)
    • 5120 x 3200 pixels
    • On-board graphics card maximum resolution (HDMI)
    • 4096 x 2160 pixels
    • On-board graphics card model
    • Intel UHD Graphics 770
    • On-board graphics card OpenGL version
    • 4.5
    • On-board graphics card outputs supported
    • Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
    • On-board graphics card refresh rate at maximum resolution (DisplayPort)
    • 60 Hz
    • On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)
    • 120 Hz
    • On-board graphics card refresh rate at maximum resolution (HDMI)
    • 60 Hz
    • Logistics data
    • Harmonized System (HS) code
    • 85423119
    • Memory
    • ECC
    • Yes
    • Maximum internal memory supported by processor
    • 128 GB
    • Memory bandwidth (max)
    • 76.8 GB/s
    • Memory channels
    • Dual-channel
    • Memory types supported by processor
    • DDR4-SDRAM, DDR5-SDRAM
    • Operational conditions
    • Tjunction
    • 100 °C
    • Other features
    • Graphics output
    • eDP 1.4b, DP 1.4a, HDMI 2.1
    • Maximum internal memory
    • 128 GB
    • Packaging data
    • Package type
    • Retail box
    • Processor
    • Box
    • Yes
    • Bus type
    • DMI4
    • Cooler included
    • No
    • Maximum number of DMI lanes
    • 8
    • Maximum turbo power
    • 117 W
    • Memory bandwidth supported by processor (max)
    • 76.8 GB/s
    • Number of Cores
    • 6
    • Performance cores
    • 6
    • Performance-core base frequency
    • 3 GHz
    • Performance-core boost frequency
    • 4.6 GHz
    • Processor
    • i5-12500
    • Processor ARK ID
    • 96144
    • Processor base power
    • 65 W
    • Processor boost frequency
    • 4.6 GHz
    • Processor cache
    • 18 MB
    • Processor cache type
    • Smart Cache
    • Processor codename
    • Alder Lake
    • Processor family
    • Intel® Core™ i5
    • Processor generation
    • 12th gen Intel® Core™ i5
    • Processor manufacturer
    • Intel
    • Processor operating modes
    • 64-bit
    • Processor socket
    • LGA 1700
    • Processor threads
    • 12
    • Processor special features
    • Enhanced Intel SpeedStep Technology
    • Yes
    • Intel 64
    • Yes
    • Intel Stable Image Platform Program (SIPP)
    • Yes
    • Intel Trusted Execution Technology
    • Yes
    • Intel Turbo Boost Max Technology 3.0
    • No
    • Intel Virtualization Technology (VT-x)
    • Yes
    • Intel Virtualization Technology for Directed I/O (VT-d)
    • Yes
    • Intel vPro® Enterprise Platform Eligibility
    • Yes
    • Intel vPro® Essentials Platform Eligibility
    • Yes
    • Intel VT-x with Extended Page Tables (EPT)
    • Yes
    • Intel® Active Management Technology (Intel® AMT)
    • Yes
    • Intel® AES New Instructions (Intel® AES-NI)
    • Yes
    • Intel® Boot Guard
    • Yes
    • Intel® Clear Video HD Technology (Intel® CVT HD)
    • Yes
    • Intel® Control-flow Enforcement Technology (CET)
    • Yes
    • Intel® Deep Learning Boost (Intel® DL Boost)
    • Yes
    • Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0
    • Yes
    • Intel® Hardware Shield Eligibility
    • Yes
    • Intel® Hyper Threading Technology (Intel® HT Technology)
    • Yes
    • Intel® One-Click Recovery
    • Yes
    • Intel® Optane™ Memory Ready
    • Yes
    • Intel® OS Guard
    • Yes
    • Intel® Quick Sync Video Technology
    • Yes
    • Intel® Secure Key
    • Yes
    • Intel® Speed Shift Technology
    • Yes
    • Intel® Standard Manageability (ISM)
    • Yes
    • Intel® Thread Director
    • No
    • Intel® Threat Detection Technology (TDT)
    • Yes
    • Intel® Total Memory Encryption
    • Yes
    • Intel® Total Memory Encryption - Multi Key
    • Yes
    • Intel® Turbo Boost Technology
    • 2.0
    • Intel® Virtualization Technology with Redirect Protection (VT-rp)
    • Yes
    • Intel® Volume Management Device (VMD)
    • Yes
    • Intel® vPro™ Platform Eligibility
    • Yes
    • Mode-based Execute Control (MBE)
    • Yes
    • Technical details
    • Launch date
    • Q1'22
    • OpenCL version
    • 2.1
    • Status
    • Launched
    • Target market
    • Gaming
    • Weight & dimensions
    • Processor package size
    • 45 x 37.5 mm
