TP-Link TL-SG1005P-PD network switch Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Roll over image to zoom inClick to Open expanded view
TP-Link TL-SG1005P-PD network switch Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
TP-Link TL-SG1005P-PD network switch Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
TP-Link TL-SG1005P-PD network switch Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
TP-Link TL-SG1005P-PD network switch Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
TP-Link TL-SG1005P-PD network switch Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
TP-Link TL-SG1005P-PD network switch Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Print
Model: TL-SG1005P-PD
EAN: 4895252501124

TP-Link TL-SG1005P-PD network switch Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

Manufacturer:
TP-LINK
TP-Link TL-SG1005P-PD, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Wall mountable
Please log in to see your price
Included in the cost of this product is the WEEE recycling charge.

Click here for details

Related products

Description

TP-Link TL-SG1005P-PD. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 2000 entries, Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3i, IEEE 802.3u,.... Power over Ethernet (PoE). Wall mountable
  • Powered by PoE++/PoE+/PoE
  • Up to 66 W PoE Budget*
  • Long-Range PoE+ (250 m**)
  • PoE Auto Recovery
  • Plug and Play
  • Multicast Optimization
  • Silent Operation
  • Durable Metal Casing

Product Properties

  • Model
  • TL-SG1005P-PD
  • EAN
  • 4895252501124
  • Bullet points
  • Point
  • Durable metal casing
    Long-Range PoE+ (250 m**)
    Multicast Optimization
    Plug and Play
    PoE Auto Recovery
    Powered by PoE++/PoE+/PoE
    Silent Operation
    Up to 66 W PoE Budget*
  • Certificates
  • Certification
  • CE, FCC, RoHS
  • Data transmission
  • Forwarding rate
  • 7.44 Mpps
  • MAC address table
  • 2000 entries
  • Store-and-forward
  • Yes
  • Switching capacity
  • 10 Gbit/s
  • Design
  • LED indicators
  • Yes
  • Number of fans
  • 0 fan(s)
  • Product colour
  • Black
  • Wall mountable
  • Yes
  • Management features
  • Quality of Service (QoS) support
  • Yes
  • Network
  • 10G support
  • Yes
  • Auto MDI/MDI-X
  • Yes
  • Auto-negotiation
  • Yes
  • Cable types supported
  • Cat3, Cat4, Cat5, Cat5e, Cat6
  • Copper ethernet cabling technology
  • 10BASE-T, 100BASE-TX, 1000BASE-T
  • Flow control support
  • Yes
  • MAC address auto-aging supported
  • Yes
  • MAC address auto-learning supported
  • Yes
  • Networking standards
  • IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
  • Operational conditions
  • Heat dissipation
  • 233.206 BTU/h
  • Operating relative humidity (H-H)
  • 10 - 90%
  • Operating temperature (T-T)
  • -30 - 70 °C
  • Storage relative humidity (H-H)
  • 5 - 90%
  • Storage temperature (T-T)
  • -40 - 70 °C
  • Packaging content
  • User guide
  • Yes
  • Packaging data
  • Package type
  • Box
  • Performance
  • Fanless
  • Yes
  • Ports & interfaces
  • Installed SFP modules quantity
  • 0
  • Installed SFP+ modules quantity
  • 0
  • Switch Number of Ports
  • 5
  • Switch Port Speed
  • Gigabit Ethernet (10/100/1000)
  • Power
  • Power consumption (max)
  • 68.59 W
  • Power source
  • PoE
  • Power supply included
  • No
  • Power over Ethernet (PoE)
  • Power over Ethernet (PoE)
  • Yes
  • Power over Ethernet (PoE) ports quantity
  • 5
  • Total Power over Ethernet (PoE) budget
  • 66 W
  • Security
  • IGMP snooping
  • Yes
  • Weight & dimensions
  • Depth
  • 101 mm
  • Height
  • 25 mm
  • Width
  • 158 mm
