Description

TP-LINK T1500G-8T. Switch type: Managed, Switch layer: L2/L3/L4. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 8000 entries, Switching capacity: 16 Gbit/s. Networking standards: IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ab,IEEE.... Power connector: DC-in jack. Power over Ethernet (PoE)

802.3af compliant PoE Port8 allows receiving power from a PoE source
Gigabit Ethernet connections on all ports provide full speed of data transferring
Advanced security features include IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm Control, DHCP Snooping, 802.1X, and Radius Authentication
L2/L3/L4 QoS and IGMP snooping optimize voice and video applications
WEB/CLI managed modes, SNMP, RMON bring abundant management features
Dual Firmware Image improves reliability and up-time of your network

Product Properties

Manufacturer
TP-LINK

Model
T1500G-8T

EAN
6935364083045

Bullet points

Point
802.3af compliant PoE Port8 allows receiving power from a PoE source

Dual Firmware Image improves reliability and up-time of your network

Gigabit Ethernet connections on all ports provide full speed of data transferring

L2/L3/L4 QoS and IGMP snooping optimize voice and video applications

WEB/CLI managed modes, SNMP, RMON bring abundant management features

Data transmission

Forwarding rate
11.9 Mpps

Jumbo frames
9216

Jumbo frames support
Y

MAC address table
8000 entries

Number of queues
4

Switching capacity
16 Gbit/s

Design

Certification
CE, FCC, RoHS

Product colour
Black

Management features

ARP inspection
Y

Configuring Location Settings (CLI)
Y

Quality of Service (QoS) support
Y

Switch layer
L2/L3/L4

Switch type
Managed

Multicast features

Multicast support
Y

Network

10G support
N

Flow control support
Y

Networking standards
IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z

Port mirroring
Y

Spanning tree protocol
Y

Virtual LAN features
Voice VLAN

VLAN support
Y

Operational conditions

Operating relative humidity (H-H)
10 - 90%

Operating temperature (T-T)
0 - 40 °C

Storage relative humidity (H-H)
5 - 90%

Storage temperature (T-T)
-40 - 70 °C

Packaging data

AC adapter included
Y

Resource CD
Y

Rubber feet
Y

User guide
Y

Performance

Firmware upgradeable
Y

Ports & interfaces

Power connector
DC-in jack

Switch Number of Ports
8

Switch Port Speed
Gigabit Ethernet (10/100/1000)

Power

AC input frequency
50 - 60 Hz

AC input voltage
100 - 240 V

Output current
1 A

Output voltage
12 V

Power consumption (typical)
5.75 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Y

Protocols

Management protocols
IGMPv1,IGMPv2,IGMPv3

Security

BPDU filtering/protection
Y

DHCP features
DHCP snooping

IGMP snooping
Y

IP-MAC-Port binding
Y

Queue scheduling algorithms
SP, WRR+SP, Weighted Round Robin (WRR)

Root protection
Y

SSH/SSL support
Y

Static port security
Y

Weight & dimensions

Depth
126 mm

Height
26 mm

Width
209 mm

TP-LINK T1500G-8T network switch Managed L2/L3/L4 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
