Description

Samsung LH37SHFPLBB. Display diagonal: 94 cm (37"), Display technology: LED, Display resolution: 1920 x 540 pixels. Product design: Digital signage flat panel, Product colour: Black, Orientation: Horizontal/Vertical. Power consumption (typical): 56 W, Power consumption (standby): 0.5 W, AC input voltage: 100 - 240 V. Processor family: ARM Cortex, Processor model: Cortex-A9, Processor frequency: 1 GHz. Width: 915.8 mm, Depth: 39.9 mm, Height: 281.1 mm

Product Properties

Manufacturer
Samsung

Model
LH37SHFPLBB/EN

EAN
8806088409214

Audio

Built-in speaker(s)
N

Computer system

Computer system
Y

Processor cores
4

Processor family
ARM Cortex

Processor frequency
1 GHz

Processor model
Cortex-A9

Design

Orientation
Horizontal/Vertical

Panel mounting interface
400 x 200 mm

Product colour
Black

Product design
Digital signage flat panel

VESA mounting
Y

Display

Active display area (W x H)
899.712 x 253.044 mm

Colour gamut
72%

Contrast ratio (typical)
4000:1

Display brightness
700 cd/m²

Display number of colours
16.78 million colours

Horizontal scan range
54 - 69.75 kHz

Native aspect ratio
16:4.5

Pixel pitch
0.4686 x 0.4686 mm

Response time
16 ms

Screen Resolution
1920 x 540 pixels

Screen Size
94 cm (37")

Screen Type
94 cm

Screen Type
LED

Touchscreen
N

Vertical scan range
48 - 62 Hz

Viewing angle, horizontal
178°

Viewing angle, vertical
178°

Operational conditions

Operating relative humidity (H-H)
10 - 80%

Operating temperature (T-T)
0 - 40 °C

Other features

Energy efficiency class (old)
C

Manual
Y

Plug and Play
Y

Packaging content

Batteries included
Y

Cables included
AC

Handheld remote control
Y

Packaging data

Package depth
122 mm

Package height
369 mm

Package volume
8500 cm³

Package width
1102 mm

Performance

HDCP
N

Multi-display supported
Y

TV tuner integrated
N

Ports & interfaces

DisplayPorts quantity
2

DVI port
Y

DVI-I ports quantity
1

Ethernet LAN
Y

Ethernet LAN (RJ-45) ports
1

HDMI ports
1

PC Audio in
Y

Remote (IR) input
1

Remote (IR) output
1

RS-232 interface
Y

RS-232C
Y

USB port
Y

USB ports quantity
1

USB version
2.0

VGA (D-Sub) input ports
1

Power

AC input frequency
50 - 60 Hz

AC input voltage
100 - 240 V

Power consumption (standby)
0.5 W

Power consumption (typical)
56 W

Weight & dimensions

Depth
39.9 mm

Height
281.1 mm

Weight
6.6 kg

Width
915.8 mm

Samsung LH37SHFPLBB signage display Digital signage flat panel 94 cm (37") LED Black
