Description

MSI Trident 9SD-234. Processor frequency: 3.6 GHz, Processor family: 9th gen Intel® Core™ i7, Processor model: i7-9700K. Internal memory: 16 GB, Internal memory type: DDR4-SDRAM, Memory clock speed: 2400 MHz. Total storage capacity: 1256 GB, Storage media: HDD+SSD. On-board graphics adapter model: Intel® UHD Graphics 630, Discrete graphics adapter model: NVIDIA® GeForce RTX™ 2070. Operating system installed: Windows 10 Home, Operating system architecture: 64-bit. Power supply: 650 W. Chassis type: Desktop. Product type: PC

9th Gen Intel® Core™ i9-9900K / i7-9700K processor
Windows 10 Home
GeForce RTX™ 2080 Ti / 2080 / 2070 graphics
10 liters in size, the most compact gaming desktop
Silent Storm Cooling 3
Support 4K gaming experience
Tempered Glass Side Panel
Easy upgrade
Compact, light weight and easy to transport case
Nahimic 3 Audio Enhancer
Mystic Light RGB LED design, customize your look

Intel® Identity Protection Technology (Intel® IPT)

Protect Your Identity and Business Intel® Identity Protection Technology (Intel® IPT) protects enterprises from being penetrated by stolen credentials and online user account access with an added layer of hardware-based security and authentication as well as a multifactor authentication framework to manage different authentication methods.

Intel® Turbo Boost Technology

Higher Performance When You Need It Most Intel® Turbo Boost Technology 2.01 accelerates processor and graphics performance by increasing the operating frequency when operating below specification limits. The maximum frequency varies depending on workload, hardware, software, and overall system configuration.

Product Properties

Manufacturer
MSI

Model
9S6-B92631-234

EAN
4719072632922

Bullet points

Point
10 liters in size, the most compact gaming desktop

9th Gen Intel® Core™ i9-9900K / i7-9700K processor

Compact, light weight and easy to transport case

Easy upgrade

GeForce RTX™ 2080 Ti / 2080 / 2070 graphics

Mystic Light RGB LED design, customize your look

Nahimic 3 Audio Enhancer

Silent Storm Cooling 3

Support 4K gaming experience

Tempered Glass Side Panel

Windows 10 Home

Design

Chassis type
Desktop

Placement supported
Vertical

Product colour
Black

Graphics

CUDA
Y

Discrete graphics adapter
Y

Discrete graphics adapter model
NVIDIA® GeForce RTX™ 2070

Discrete graphics memory type
GDDR6

Graphics Memory
8 GB

Graphics Processor
Intel® UHD Graphics 630

Maximum on-board graphics adapter memory
64 GB

Number of discrete graphics adapters
1

Number of displays supported (on-board graphics)
3

NVIDIA G-SYNC
Y

NVIDIA GameWorks VR
Y

On-board graphics adapter
Y

On-board graphics adapter base frequency
350 MHz

On-board graphics adapter DirectX version
12.0

On-board graphics adapter dynamic frequency (max)
1200 MHz

On-board graphics adapter family
Intel® UHD Graphics

On-board graphics adapter ID
0x3E98

On-board graphics adapter OpenGL version
4.5

Memory

Internal memory type
DDR4-SDRAM

Memory channels
Dual-channel

Memory clock speed
2400 MHz

Memory Installed
16 GB

Memory Slot Support
64 GB

Memory slots
2x DIMM

Network

Bluetooth
Y

Bluetooth version
5.0

Cabling technology
10/100/1000Base-T(X)

Ethernet LAN
Y

Ethernet LAN data rates
10,100,1000 Mbit/s

Top Wi-Fi standard
Wi-Fi 5 (802.11ac)

Wi-Fi
Y

Wi-Fi standards
802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n)

WLAN controller model
Intel Dual Band Wireless-AC 9462

Packaging content

Display included
N

Manual
Y

Power cord included
Y

Performance

Audio output channels
7.1 channels

Market positioning
Gaming

Motherboard chipset
Intel Z390

Product type
PC

Virtual Reality (VR) ready
Y

Ports & interfaces

DisplayPorts quantity
1

DVI port
N

Ethernet LAN (RJ-45) ports
1

HDMI ports
1

HDMI version
1.4

Headphone outputs
1

Line-in
Y

Line-out
Y

Microphone in
Y

On/off button
Y

S/PDIF out port
Y

USB 2.0 ports quantity
3

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2

Power

80 PLUS certification
80 PLUS Gold

Power supply
650 W

Processor

Bus type
DMI2

ECC supported by processor
N

Maximum internal memory supported by processor
128 GB

Maximum number of PCI Express lanes
16

Memory bandwidth supported by processor (max)
41.6 GB/s

Memory clock speeds supported by processor
2666 MHz

Memory types supported by processor
DDR4-SDRAM

Number of Cores
8

Number of processors installed
1

PCI Express configurations
1x16,2x8,1x8+2x4

PCI Express slots version
3.0

Processor
i7-9700K

Processor boost frequency
4.9 GHz

Processor cache
12 MB

Processor cache type
Smart Cache

Processor codename
Coffee Lake

Processor family
9th gen Intel® Core™ i7

Processor frequency
3.6 GHz

Processor lithography
14 nm

Processor manufacturer
Intel

Processor operating modes
64-bit

Processor socket
LGA 1151 (Socket H4)

Processor threads
8

System bus rate
8 GT/s

Thermal Design Power (TDP)
95 W

Tjunction
100 °C

Processor special features

CPU configuration (max)
1

Embedded options available
N

Enhanced Intel SpeedStep Technology
Y

Execute Disable Bit
Y

Idle States
Y

Intel 64
Y

Intel Clear Video Technology
Y

Intel Software Guard Extensions (Intel SGX)
Y

Intel Stable Image Platform Program (SIPP)
Y

Intel Trusted Execution Technology
Y

Intel TSX-NI
Y

Intel Virtualization Technology (VT-x)
Y

Intel Virtualization Technology for Directed I/O (VT-d)
Y

Intel VT-x with Extended Page Tables (EPT)
Y

Intel® AES New Instructions (Intel® AES-NI)
Y

Intel® Clear Video HD Technology (Intel® CVT HD)
Y

Intel® Hyper Threading Technology (Intel® HT Technology)
N

Intel® Identity Protection Technology (Intel® IPT)
Y

Intel® InTru™ 3D Technology
Y

Intel® OS Guard
Y

Intel® Quick Sync Video Technology
Y

Intel® Secure Key
Y

Intel® Turbo Boost Technology
2.0

Processor ARK ID
186604

Processor package size
37.5 x 37.5 mm

Scalability
1S

Supported instruction sets
SSE4.1,SSE4.2,AVX 2.0

Thermal Monitoring Technologies
Y

Thermal solution specification
PCG 2015D

Software

Operating system architecture
64-bit

Operating system installed
Windows 10 Home

Storage

Card reader integrated
N

HDD capacity
1000 GB

Number of HDDs installed
1

Number of SSDs installed
1

Optical drive type
N

SSD capacity
256 GB

SSD form factor
M.2

Storage Capacity
1256 GB

Storage type
HDD+SSD

Total HDDs capacity
1000 GB

Total SSDs capacity
256 GB

Weight & dimensions

Depth
382.7 mm

Height
296.4 mm

Package weight
9.5 kg

Weight
6.55 kg

Width
129.7 mm

MSI Trident 9SD-234 DDR4-SDRAM i7-9700K Desktop 9th gen Intel® Core™ i7 16 GB 1256 GB HDD+SSD Windows 10 Home PC Black
