Description

MSI Trident 3 8RC-030EU. Processor frequency: 2.8 GHz, Processor family: 8th gen Intel® Core™ i5, Processor model: i5-8400. Internal memory: 8 GB, Internal memory type: DDR4-SDRAM, Memory clock speed: 2400 MHz. Total storage capacity: 1000 GB, Storage media: HDD. On-board graphics adapter model: Intel® UHD Graphics 630, Discrete graphics adapter model: NVIDIA® GeForce® GTX 1050. Operating system installed: Windows 10 Home, Operating system architecture: 64-bit. Power supply: 230 W. Chassis type: Desktop. Product type: PC

Intel® Identity Protection Technology (Intel® IPT)

Protect Your Identity and Business Intel® Identity Protection Technology (Intel® IPT) protects enterprises from being penetrated by stolen credentials and online user account access with an added layer of hardware-based security and authentication as well as a multifactor authentication framework to manage different authentication methods.

Intel® Turbo Boost Technology

Higher Performance When You Need It Most Intel® Turbo Boost Technology 2.01 accelerates processor and graphics performance by increasing the operating frequency when operating below specification limits. The maximum frequency varies depending on workload, hardware, software, and overall system configuration.

Conflict-Free processor

Does not contain "conflict minerals": tantalum, tin, tungsten, and gold.

Product Properties

Manufacturer
MSI

Model
9S6-B92011-030

EAN
4719072562076

Design

Chassis type
Desktop

Product colour
Black

Graphics

CUDA
Y

Discrete graphics adapter
Y

Discrete graphics adapter model
NVIDIA® GeForce® GTX 1050

Discrete graphics memory type
GDDR5

Graphics Memory
2 GB

Graphics Processor
Intel® UHD Graphics 630

Maximum on-board graphics adapter memory
64 GB

Number of discrete graphics adapters
1

Number of displays supported (on-board graphics)
3

Number of execution units
23

NVIDIA G-SYNC
N

NVIDIA GameWorks VR
N

On-board graphics adapter
Y

On-board graphics adapter base frequency
350 MHz

On-board graphics adapter DirectX version
12.0

On-board graphics adapter dynamic frequency (max)
1050 MHz

On-board graphics adapter ID
0x3E92

On-board graphics adapter OpenGL version
4.5

Memory

Internal memory type
DDR4-SDRAM

Memory channels
Dual-channel

Memory clock speed
2400 MHz

Memory Installed
8 GB

Memory layout (slots x size)
1 x 8 GB

Memory Slot Support
32 GB

Memory slots
2x SO-DIMM

Non-ECC
Y

Network

Bluetooth
Y

Bluetooth version
5.0

Ethernet LAN
Y

Ethernet LAN data rates
10,100,1000 Mbit/s

Wi-Fi
Y

Wi-Fi standards
802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n)

Packaging content

AC adapter included
Y

Cables included
HDMI

Display included
N

Performance

Audio output channels
5.1 channels

BIOS type
UEFI AMI

Market positioning
Gaming

Motherboard chipset
Intel H310 Express

Product type
PC

Virtual Reality (VR) ready
Y

Ports & interfaces

DVI port
N

Ethernet LAN (RJ-45) ports
1

HDMI ports
3

Headphone outputs
1

Line-out
Y

Microphone in
Y

USB 2.0 ports quantity
4

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
3

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1

Power

Power supply
230 W

Processor

Bus type
DMI3

ECC supported by processor
N

Maximum internal memory supported by processor
64 GB

Maximum number of PCI Express lanes
16

Memory bandwidth supported by processor (max)
41.6 GB/s

Memory clock speeds supported by processor
2666 MHz

Memory types supported by processor
DDR4-SDRAM

Number of Cores
6

Number of processors installed
1

PCI Express configurations
1x16,1x8+2x4,2x8

PCI Express slots version
3.0

Processor
i5-8400

Processor boost frequency
4 GHz

Processor cache
9 MB

Processor cache type
Smart Cache

Processor codename
Coffee Lake

Processor family
8th gen Intel® Core™ i5

Processor frequency
2.8 GHz

Processor lithography
14 nm

Processor manufacturer
Intel

Processor operating modes
64-bit

Processor socket
LGA 1151 (Socket H4)

Processor threads
6

System bus rate
8 GT/s

Thermal Design Power (TDP)
65 W

Tjunction
100 °C

Processor special features

Conflict-Free processor
Y

CPU configuration (max)
1

Embedded options available
N

Enhanced Intel SpeedStep Technology
Y

Execute Disable Bit
Y

Idle States
Y

Intel 64
Y

Intel Clear Video Technology
Y

Intel Enhanced Halt State
Y

Intel Identity Protection Technology version
1.00

Intel Secure Key Technology version
1.00

Intel Software Guard Extensions (Intel SGX)
Y

Intel Stable Image Platform Program (SIPP)
N

Intel Stable Image Platform Program (SIPP) version
0.00

Intel Trusted Execution Technology
N

Intel TSX-NI
N

Intel TSX-NI version
0.00

Intel Virtualization Technology (VT-x)
Y

Intel Virtualization Technology for Directed I/O (VT-d)
Y

Intel VT-x with Extended Page Tables (EPT)
Y

Intel® AES New Instructions (Intel® AES-NI)
Y

Intel® Clear Video HD Technology (Intel® CVT HD)
Y

Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
Y

Intel® Hyper Threading Technology (Intel® HT Technology)
N

Intel® Identity Protection Technology (Intel® IPT)
Y

Intel® InTru™ 3D Technology
Y

Intel® OS Guard
Y

Intel® Quick Sync Video Technology
Y

Intel® Secure Key
Y

Intel® Turbo Boost Technology
2.0

Processor ARK ID
126687

Processor package size
37.5 x 37.5 mm

Scalability
1S

Supported instruction sets
AVX 2.0,SSE4.1,SSE4.2

Thermal Monitoring Technologies
Y

Thermal solution specification
PCG 2015C

Software

Operating system architecture
64-bit

Operating system installed
Windows 10 Home

Storage

Card reader integrated
N

HDD capacity
1000 GB

HDD speed
7200 RPM

Number of HDDs installed
1

Number of storage drives installed
1

Optical drive type
N

Storage Capacity
1000 GB

Storage type
HDD

Total HDDs capacity
1000 GB

Weight & dimensions

Depth
232.5 mm

Height
71.8 mm

Package weight
6.09 kg

Weight
3.17 kg

Width
346.2 mm

MSI Trident 3 8RC-030EU DDR4-SDRAM i5-8400 Desktop 8th gen Intel® Core™ i5 8 GB 1000 GB HDD Windows 10 Home PC Black
