Description

MSI Infinite X Plus 9SE-297EU. Processor frequency: 3.6 GHz, Processor family: 9th gen Intel® Core™ i7, Processor model: i7-9700K. Internal memory: 16 GB, Internal memory type: DDR4-SDRAM, Memory clock speed: 2666 MHz. Total storage capacity: 2512 GB, Storage media: HDD+SSD, Optical drive type: DVD Super Multi. On-board graphics adapter model: Intel® UHD Graphics 630, Discrete graphics adapter model: NVIDIA® GeForce RTX™ 2080. Operating system installed: Windows 10 Home, Operating system architecture: 64-bit. Chassis type: Desktop. Product type: PC

Windows 10 Home
9th Gen Intel® Core™ i9 -9900K processor with DDR4 memory
Up to MSI GeForce® RTX 2080 Ti 11GB GDDR6 graphics
Exclusive Silent Storm Cooling 3 PRO cooling system enhances system cooling and keeps it silent
Mystic Light RGB LED design to customize your Gaming PC
Easy to upgrade - designed to upgrade your components with an ease
Built-in carry handle – Take your Gaming Desktop everywhere with the easy to carry handle
Vertical graphics optimal protection for your components during transport
Load your games in seconds with Super RAID 4
Nahimic 3.0 Audio Enhancer
Audio Boost: Reward your ears with studio grade sound quality
Exclusive MSI Dragon Center
Super Charger : super power delivery, fast charge you mobile device
Super speed USB 3.1 Gen 1 Type C with reversible design

Intel® Identity Protection Technology (Intel® IPT)

Protect Your Identity and Business Intel® Identity Protection Technology (Intel® IPT) protects enterprises from being penetrated by stolen credentials and online user account access with an added layer of hardware-based security and authentication as well as a multifactor authentication framework to manage different authentication methods.

Intel® Turbo Boost Technology

Higher Performance When You Need It Most Intel® Turbo Boost Technology 2.01 accelerates processor and graphics performance by increasing the operating frequency when operating below specification limits. The maximum frequency varies depending on workload, hardware, software, and overall system configuration.

Product Properties

Manufacturer
MSI

Model
9S6-B91641-297

EAN
4719072618025

Bullet points

Point
9th Gen Intel® Core™ i9 -9900K processor with DDR4 memory

Audio Boost: Reward your ears with studio grade sound quality

Built-in carry handle – Take your Gaming Desktop everywhere with the easy to carry handle

Easy to upgrade - designed to upgrade your components with an ease

Exclusive MSI Dragon Center

Exclusive Silent Storm Cooling 3 PRO cooling system enhances system cooling and keeps it silent

Load your games in seconds with Super RAID 4

Mystic Light RGB LED design to customize your Gaming PC

Nahimic 3.0 Audio Enhancer

Super Charger : super power delivery, fast charge you mobile device

Super speed USB 3.1 Gen 1 Type C with reversible design

Up to MSI GeForce® RTX 2080 Ti 11GB GDDR6 graphics

Vertical graphics optimal protection for your components during transport

Windows 10 Home

Design

Chassis type
Desktop

Placement supported
Vertical

Product colour
Black, Red

Viewing window
Y

Volume
42 L

Graphics

Discrete graphics adapter
Y

Discrete graphics adapter model
NVIDIA® GeForce RTX™ 2080

Discrete graphics memory type
GDDR6

Graphics Memory
8 GB

Graphics Processor
Intel® UHD Graphics 630

Maximum on-board graphics adapter memory
64 GB

Number of discrete graphics adapters
1

Number of displays supported (on-board graphics)
3

NVIDIA G-SYNC
Y

On-board graphics adapter
Y

On-board graphics adapter 4K support
Y

On-board graphics adapter base frequency
350 MHz

On-board graphics adapter DirectX version
12.0

On-board graphics adapter dynamic frequency (max)
1200 MHz

On-board graphics adapter family
Intel® UHD Graphics

On-board graphics adapter ID
0x3E98

On-board graphics adapter OpenGL version
4.5

Memory

Internal memory type
DDR4-SDRAM

Memory channels
Dual-channel

Memory clock speed
2666 MHz

Memory Installed
16 GB

Memory layout (slots x size)
2 x 8 GB

Memory Slot Support
64 GB

Memory slots
4x DIMM

Non-ECC
Y

Network

Antenna type
2x2

Bluetooth
Y

Bluetooth version
5.0

Cabling technology
10/100/1000Base-T(X)

Ethernet LAN
Y

Ethernet LAN data rates
10,100,1000 Mbit/s

Top Wi-Fi standard
Wi-Fi 5 (802.11ac)

Wi-Fi
Y

Wi-Fi standards
802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n)

WLAN controller model
Intel Dual Band Wireless-AC 9462

Other features

Optical drives quantity
1

Packaging content

AC adapter included
Y

Display included
N

Manual
Y

Performance

Audio output channels
7.1 channels

Audio system
High Definition Audio

Market positioning
Gaming

Motherboard chipset
Intel Z390

Product type
PC

Ports & interfaces

DC-in jack
Y

DisplayPort version
1.2

DisplayPorts quantity
1

DVI port
Y

Ethernet LAN (RJ-45) ports
1

HDMI ports
1

HDMI version
1.4

Headphone outputs
1

Line-in
Y

Line-out
Y

Microphone in
Y

Number of speaker outputs
5

On/off button
Y

PS/2 ports quantity
1

S/PDIF out port
Y

USB 2.0 ports quantity
5

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1

Processor

Bus type
DMI3

ECC supported by processor
N

Maximum internal memory supported by processor
128 GB

Maximum number of PCI Express lanes
16

Memory bandwidth supported by processor (max)
41.6 GB/s

Memory clock speeds supported by processor
2666 MHz

Memory types supported by processor
DDR4-SDRAM

Number of Cores
8

Number of processors installed
1

PCI Express configurations
1x16,2x8,1x8+2x4

PCI Express slots version
3.0

Processor
i7-9700K

Processor boost frequency
4.9 GHz

Processor cache
12 MB

Processor cache type
Smart Cache

Processor codename
Coffee Lake

Processor family
9th gen Intel® Core™ i7

Processor frequency
3.6 GHz

Processor lithography
14 nm

Processor manufacturer
Intel

Processor operating modes
64-bit

Processor socket
LGA 1151 (Socket H4)

Processor threads
8

System bus rate
8 GT/s

Thermal Design Power (TDP)
95 W

Tjunction
100 °C

Processor special features

CPU configuration (max)
1

Embedded options available
N

Enhanced Intel SpeedStep Technology
Y

Execute Disable Bit
Y

Idle States
Y

Intel 64
Y

Intel Clear Video Technology
Y

Intel Software Guard Extensions (Intel SGX)
Y

Intel Stable Image Platform Program (SIPP)
Y

Intel Trusted Execution Technology
Y

Intel TSX-NI
Y

Intel Virtualization Technology (VT-x)
Y

Intel Virtualization Technology for Directed I/O (VT-d)
Y

Intel VT-x with Extended Page Tables (EPT)
Y

Intel® AES New Instructions (Intel® AES-NI)
Y

Intel® Clear Video HD Technology (Intel® CVT HD)
Y

Intel® Hyper Threading Technology (Intel® HT Technology)
N

Intel® Identity Protection Technology (Intel® IPT)
Y

Intel® InTru™ 3D Technology
Y

Intel® OS Guard
Y

Intel® Quick Sync Video Technology
Y

Intel® Secure Key
Y

Intel® Turbo Boost Technology
2.0

Processor ARK ID
186604

Processor package size
37.5 x 37.5 mm

Scalability
1S

Supported instruction sets
SSE4.1,SSE4.2,AVX 2.0

Thermal Monitoring Technologies
Y

Thermal solution specification
PCG 2015D

Software

Bundled software
Drivers & MSI Utilities MSI Dragon center

Operating system architecture
64-bit

Operating system installed
Windows 10 Home

Trial software
Anti-Virus

Storage

Card reader integrated
N

HDD capacity
2000 GB

HDD interface
SATA III

HDD size
3.5"

Number of HDDs installed
1

Number of SSDs installed
1

Optical drive type
DVD Super Multi

RAID levels
4

RAID support
Y

SSD capacity
512 GB

SSD form factor
M.2

SSD interface
PCI Express

Storage Capacity
2512 GB

Storage type
HDD+SSD

Weight & dimensions

Depth
450 mm

Height
488 mm

Weight
15 kg

Width
210 mm

MSI Infinite X Plus 9SE-297EU DDR4-SDRAM i7-9700K Desktop 9th gen Intel® Core™ i7 16 GB 2512 GB HDD+SSD Windows 10 Home PC Black, Red
