Description

MSI Infinite X 8RC-083UK. Processor frequency: 3.7 GHz, Processor family: 8th gen Intel® Core™ i7, Processor model: i7-8700K. Internal memory: 16 GB, Internal memory type: DDR4-SDRAM, Memory clock speed: 2400 MHz. Total storage capacity: 2256 GB, Storage media: HDD+SSD, Optical drive type: DVD Super Multi. On-board graphics adapter model: Intel® UHD Graphics 630, Discrete graphics adapter model: NVIDIA® GeForce® GTX 1060. Operating system installed: Windows 10 Home. Power supply: 500 W. Chassis type: Desktop. Product type: PC

Intel® Identity Protection Technology (Intel® IPT)

Protect Your Identity and Business Intel® Identity Protection Technology (Intel® IPT) protects enterprises from being penetrated by stolen credentials and online user account access with an added layer of hardware-based security and authentication as well as a multifactor authentication framework to manage different authentication methods.

Intel® Turbo Boost Technology

Higher Performance When You Need It Most Intel® Turbo Boost Technology 2.01 accelerates processor and graphics performance by increasing the operating frequency when operating below specification limits. The maximum frequency varies depending on workload, hardware, software, and overall system configuration.

Conflict-Free processor

Does not contain "conflict minerals": tantalum, tin, tungsten, and gold.

Product Properties

Manufacturer
MSI

Model
9S6-B91621-083

EAN
4719072560355

Design

Chassis type
Desktop

Product colour
Black

Graphics

CUDA
Y

Discrete graphics adapter
Y

Discrete graphics adapter model
NVIDIA® GeForce® GTX 1060

Discrete graphics memory type
GDDR5

Graphics Memory
6 GB

Graphics Processor
Intel® UHD Graphics 630

Maximum on-board graphics adapter memory
64 GB

Number of displays supported (on-board graphics)
3

Number of execution units
24

NVIDIA G-SYNC
Y

NVIDIA GameWorks VR
Y

On-board graphics adapter
Y

On-board graphics adapter base frequency
350 MHz

On-board graphics adapter DirectX version
12.0

On-board graphics adapter dynamic frequency (max)
1200 MHz

On-board graphics adapter family
Intel® UHD Graphics

On-board graphics adapter ID
0x3E92

On-board graphics adapter OpenGL version
4.5

Memory

Internal memory type
DDR4-SDRAM

Memory channels
Dual-channel

Memory clock speed
2400 MHz

Memory Installed
16 GB

Memory layout (slots x size)
2 x 8 GB

Memory Slot Support
64 GB

Memory slots
4x DIMM

Network

Cabling technology
10/100/1000Base-T(X)

Ethernet LAN
Y

Ethernet LAN data rates
10,100,1000 Mbit/s

Top Wi-Fi standard
Wi-Fi 5 (802.11ac)

Wi-Fi
Y

Wi-Fi standards
Wi-Fi 5 (802.11ac)

Packaging content

Display included
N

Performance

Motherboard chipset
Intel® Z370

Product type
PC

Ports & interfaces

DVI port
N

Ethernet LAN (RJ-45) ports
1

HDMI ports
1

Headphone outputs
1

Line-in
Y

Line-out
Y

Microphone in
Y

PS/2 ports quantity
1

USB 2.0 ports quantity
3

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
5

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1

Power

80 PLUS certification
80 PLUS Bronze

Power supply
500 W

Processor

Bus type
DMI3

ECC supported by processor
N

Maximum internal memory supported by processor
64 GB

Maximum number of PCI Express lanes
16

Memory bandwidth supported by processor (max)
41.6 GB/s

Memory clock speeds supported by processor
2666 MHz

Memory types supported by processor
DDR4-SDRAM

Number of Cores
6

Number of processors installed
1

PCI Express configurations
1x16,1x8+2x4,2x8

PCI Express slots version
3.0

Processor
i7-8700K

Processor boost frequency
4.7 GHz

Processor cache
12 MB

Processor cache type
Smart Cache

Processor codename
Coffee Lake

Processor family
8th gen Intel® Core™ i7

Processor frequency
3.7 GHz

Processor lithography
14 nm

Processor manufacturer
Intel

Processor operating modes
64-bit

Processor series
Intel Core i7-8700 Desktop Series

Processor socket
LGA 1151 (Socket H4)

Processor threads
12

System bus rate
8 GT/s

Thermal Design Power (TDP)
95 W

Tjunction
100 °C

Processor special features

Conflict-Free processor
Y

CPU configuration (max)
1

Embedded options available
N

Enhanced Intel SpeedStep Technology
Y

Execute Disable Bit
Y

Idle States
Y

Intel 64
Y

Intel Clear Video Technology
Y

Intel Enhanced Halt State
Y

Intel Identity Protection Technology version
1.00

Intel Secure Key Technology version
1.00

Intel Software Guard Extensions (Intel SGX)
Y

Intel Stable Image Platform Program (SIPP)
Y

Intel Stable Image Platform Program (SIPP) version
1.00

Intel Trusted Execution Technology
Y

Intel TSX-NI
Y

Intel TSX-NI version
1.00

Intel Virtualization Technology (VT-x)
Y

Intel Virtualization Technology for Directed I/O (VT-d)
Y

Intel VT-x with Extended Page Tables (EPT)
Y

Intel® AES New Instructions (Intel® AES-NI)
Y

Intel® Clear Video HD Technology (Intel® CVT HD)
Y

Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
Y

Intel® Hyper Threading Technology (Intel® HT Technology)
Y

Intel® Identity Protection Technology (Intel® IPT)
Y

Intel® InTru™ 3D Technology
Y

Intel® OS Guard
Y

Intel® Quick Sync Video Technology
Y

Intel® Secure Key
Y

Intel® Turbo Boost Technology
2.0

Processor ARK ID
126684

Processor package size
37.5 x 37.5 mm

Scalability
1S

Supported instruction sets
AVX 2.0,SSE4.1,SSE4.2

Thermal Monitoring Technologies
Y

Thermal solution specification
PCG 2015D

Software

Operating system installed
Windows 10 Home

Storage

Card reader integrated
N

HDD size
3.5"

Number of HDDs installed
1000

Number of SSDs installed
1

Number of storage drives installed
2

Number of storage drives supported
1

Optical drive type
DVD Super Multi

SSD capacity
256 GB

Storage Capacity
2256 GB

Storage type
HDD+SSD

Weight & dimensions

Depth
450 mm

Height
488 mm

Weight
15 kg

Width
210 mm

MSI Infinite X 8RC-083UK DDR4-SDRAM i7-8700K Desktop 8th gen Intel® Core™ i7 16 GB 2256 GB HDD+SSD Windows 10 Home PC Black
