Fujitsu PRIMERGY RX2540 M5 server 0 GB Rack (2U) Intel Xeon Silver 4208 2.1 GHz 16 GB DDR4-SDRAM 800 W
Roll over image to zoom inClick to Open expanded view
Fujitsu PRIMERGY RX2540 M5 server 0 GB Rack (2U) Intel Xeon Silver 4208 2.1 GHz 16 GB DDR4-SDRAM 800 W
Fujitsu PRIMERGY RX2540 M5 server 0 GB Rack (2U) Intel Xeon Silver 4208 2.1 GHz 16 GB DDR4-SDRAM 800 W
Fujitsu PRIMERGY RX2540 M5 server 0 GB Rack (2U) Intel Xeon Silver 4208 2.1 GHz 16 GB DDR4-SDRAM 800 W
Fujitsu PRIMERGY RX2540 M5 server 0 GB Rack (2U) Intel Xeon Silver 4208 2.1 GHz 16 GB DDR4-SDRAM 800 W
Fujitsu PRIMERGY RX2540 M5 server 0 GB Rack (2U) Intel Xeon Silver 4208 2.1 GHz 16 GB DDR4-SDRAM 800 W
Fujitsu PRIMERGY RX2540 M5 server 0 GB Rack (2U) Intel Xeon Silver 4208 2.1 GHz 16 GB DDR4-SDRAM 800 W
Print
Model: VFY:R2545SC010IN
EAN: 4059595838198

Fujitsu PRIMERGY RX2540 M5 server 0 GB Rack (2U) Intel Xeon Silver 4208 2.1 GHz 16 GB DDR4-SDRAM 800 W

Manufacturer:
Fujitsu
Fujitsu PRIMERGY RX2540 M5, 2.1 GHz, 4208, 16 GB, DDR4-SDRAM, 0 GB, Rack (2U)
Please log in to see your price
Related products

Description

Fujitsu PRIMERGY RX2540 M5. Processor family: Intel Xeon Silver, Processor frequency: 2.1 GHz, Processor model: 4208. Internal memory: 16 GB, Internal memory type: DDR4-SDRAM. Total storage capacity: 0 GB. Ethernet LAN, Cabling technology: 10/100/1000Base-T(X). Power supply: 800 W, Redundant power supply (RPS) support. Chassis type: Rack (2U)
  • Intel Xeon Silver 4208 (11MB Cache, 2.1GHz)
  • 16GB (2933MHz) DDR4-SDRAM

Product Properties

  • Model
  • VFY:R2545SC010IN
  • EAN
  • 4059595838198
  • Bullet points
  • Point
  • 16GB (2933MHz) DDR4-SDRAM
    Intel Xeon Silver 4208 (11MB Cache, 2.1GHz)
  • Design
  • Chassis type
  • Rack (2U)
  • Product colour
  • Black
  • Rack mounting
  • Yes
  • Rack rails
  • Yes
  • Expansion slots
  • PCI Express slots version
  • 3.0
  • PCI Express x16 (Gen 3.x) slots
  • 3
  • PCI Express x8 (Gen 3.x) slots
  • 3
  • Graphics
  • On-board graphics card model
  • Not available
  • Logistics data
  • Harmonized System (HS) code
  • 84714100
  • Memory
  • Internal memory type
  • DDR4-SDRAM
  • Memory clock speed
  • 2933 MHz
  • Memory Installed
  • 16 GB
  • Memory Slot Support
  • 1 TB
  • Memory slots
  • 24
  • Network
  • Cabling technology
  • 10/100/1000Base-T(X)
  • Ethernet interface type
  • Gigabit Ethernet
  • Ethernet LAN
  • Yes
  • Operational conditions
  • Operating relative humidity (H-H)
  • 10 - 85%
  • Operating temperature (T-T)
  • 5 - 40 °C
  • Ports & interfaces
  • Ethernet LAN (RJ-45) ports
  • 4
  • RS-232 ports
  • 1
  • Serial ports quantity
  • 1
  • USB 2.0 ports quantity
  • 1
  • USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
  • 5
  • VGA (D-Sub) ports quantity
  • 2
  • Power
  • Number of main power supplies
  • 1
  • Number of redundant power supplies installed
  • 1
  • Number of redundant power supplies supported
  • 2
  • Power supply
  • 800 W
  • Redundant power supply (RPS) support
  • Yes
  • Processor
  • Embedded options available
  • No
  • Execute Disable Bit
  • Yes
  • Maximum internal memory supported by processor
  • 1.02 TB
  • Maximum number of PCI Express lanes
  • 48
  • Memory clock speeds supported by processor
  • 2400 MHz
  • Memory types supported by processor
  • DDR4-SDRAM
  • Motherboard chipset
  • Intel® C624
  • Number of Cores
  • 8
  • Number of processors installed
  • 1
  • Processor
  • 4208
  • Processor boost frequency
  • 3.2 GHz
  • Processor cache
  • 11 MB
  • Processor codename
  • Cascade Lake
  • Processor family
  • Intel Xeon Silver
  • Processor frequency
  • 2.1 GHz
  • Processor generation
  • 2nd Generation Intel® Xeon® Scalable
  • Processor lithography
  • 14 nm
  • Processor manufacturer
  • Intel
  • Processor operating modes
  • 64-bit
  • Processor package size
  • 76.0 x 56.5 mm
  • Processor socket
  • LGA 3647 (Socket P)
  • Processor threads
  • 16
  • Scalability
  • 2S
  • Supported instruction sets
  • AVX-512
  • Tcase
  • 78 °C
  • Thermal Design Power (TDP)
  • 85 W
  • Processor special features
  • Enhanced Intel SpeedStep Technology
  • Yes
  • Intel 64
  • Yes
  • Intel Trusted Execution Technology
  • Yes
  • Intel TSX-NI
  • Yes
  • Intel Virtualization Technology (VT-x)
  • Yes
  • Intel Virtualization Technology for Directed I/O (VT-d)
  • Yes
  • Intel VT-x with Extended Page Tables (EPT)
  • Yes
  • Intel® AES New Instructions (Intel® AES-NI)
  • Yes
  • Intel® Hyper Threading Technology (Intel® HT Technology)
  • Yes
  • Intel® Turbo Boost Technology
  • 2.0
  • Processor ARK ID
  • 193390
  • Software
  • Compatible operating systems
  • - Microsoft Hyper-V Server R2 2012 - Microsoft Windows Server 2012 R2 Datacenter - Microsoft Windows Server 2012 R2 Standard - Microsoft Windows Server 2012 R2 Essentials - Microsoft Windows Server 2012 R2 Foundation - Microsoft Windows Storage Server 2012 R2 Standard - Microsoft Hyper-V Server 2012 - Microsoft Windows Server 2012 Datacenter - Microsoft Windows Server 2012 Standard - Microsoft Windows Server 2012 Essentials - Microsoft Windows Storage Server 2012 Standard - Microsoft Hyper-V Server 2008 R2 - Microsoft Windows Server 2008 R2 Datacenter - Microsoft Windows Server 2008 R2 Enterprise - Microsoft Windows Server 2008 R2 Standard - Microsoft Windows Small Business Server 2011 Premium Add-On - Microsoft Windows Small Business Server Standard 2011 - Microsoft Windows Server 2008 Datacenter - Microsoft Windows Server 2008 Enterprise - Microsoft Windows Server 2008 Standard - VMware vSphere 5.5 Embedded - VMware vSphere 5.5 - VMware vSphere 5.0 Embedded - VMware vSphere 5.0 - VMware vSphere 4.1 - VMware
  • Storage
  • Maximum storage capacity
  • 12 TB
  • Number of HDDs installed
  • 0
  • RAID levels
  • 5, 6
  • RAID support
  • Yes
  • Storage Capacity
  • 0 GB
  • Supported HDD sizes
  • 2.5,3.5"
  • Supported storage drive interfaces
  • SAS, Serial ATA, Serial ATA III
  • Weight & dimensions
  • Depth
  • 770 mm
  • Height
  • 86.6 mm
  • Width
  • 482.4 mm
