D-Link DGS-3000-52X network switch Managed L2 Gigabit Ethernet (10/100/1000) 1U Black
Roll over image to zoom inClick to Open expanded view
D-Link DGS-3000-52X network switch Managed L2 Gigabit Ethernet (10/100/1000) 1U Black
D-Link DGS-3000-52X network switch Managed L2 Gigabit Ethernet (10/100/1000) 1U Black
D-Link DGS-3000-52X network switch Managed L2 Gigabit Ethernet (10/100/1000) 1U Black
Print
Model: DGS-3000-52X
EAN: 790069429637

D-Link DGS-3000-52X network switch Managed L2 Gigabit Ethernet (10/100/1000) 1U Black

Manufacturer:
D-Link
D-Link DGS-3000-52X, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Rack mounting, 1U
Please log in to see your price
Related products

Description

D-Link DGS-3000-52X. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48, Console port: RJ-45. Full duplex. MAC address table: 16000 entries, Switching capacity: 176 Gbit/s. Networking standards: IEEE 802.1AX,IEEE 802.1D,IEEE 802.1ag,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.3,IEEE.... Rack mounting, Form factor: 1U

Product Properties

  • Model
  • DGS-3000-52X
  • EAN
  • 790069429637
  • Data transmission
  • Forwarding rate
  • 130.95 Mpps
  • Jumbo frames
  • 9216
  • Jumbo frames support
  • Y
  • MAC address table
  • 16000 entries
  • Packet buffer memory
  • 3 MB
  • Store-and-forward
  • Y
  • Switching capacity
  • 176 Gbit/s
  • Design
  • Certification
  • CE, FCC, C-Tick, VCCI, BSMI
  • Form factor
  • 1U
  • LED indicators
  • Activity, Fan fail, Link, Power, Speed
  • Number of fans
  • 2 fan(s)
  • Product colour
  • Black
  • Rack mounting
  • Y
  • Safety
  • cUL, CB
  • Stackable
  • Y
  • Management features
  • ARP inspection
  • Y
  • Quality of Service (QoS) support
  • Y
  • Switch layer
  • L2
  • Switch type
  • Managed
  • Web-based management
  • Y
  • Multicast features
  • Multicast Listener Discovery (MLD) snooping
  • MLD v1, MLD v2
  • Multicast support
  • Y
  • Network
  • 10G support
  • Y
  • Auto MDI/MDI-X
  • Y
  • Auto-negotiation
  • Y
  • Broadcast storm control
  • Y
  • Cable types supported
  • Cat5,Cat5e
  • Copper ethernet cabling technology
  • 10BASE-T,100BASE-TX,1000BASE-T
  • Flow control support
  • Y
  • Full duplex
  • Y
  • Head-of-line (HOL) blocking
  • Y
  • Link aggregation
  • Y
  • Networking standards
  • IEEE 802.1AX,IEEE 802.1D,IEEE 802.1ag,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3ae,IEEE 802.3ah,IEEE 802.3u,IEEE 802.3x
  • Number of VLANs
  • 4094
  • Port mirroring
  • Y
  • Spanning tree protocol
  • Y
  • Virtual LAN features
  • Private VLAN,Voice VLAN,Tagged VLAN,MAC address-based VLAN,Port-based VLAN
  • VLAN support
  • Y
  • Operational conditions
  • Heat dissipation
  • 145.948 BTU/h
  • Operating relative humidity (H-H)
  • 0 - 95%
  • Operating temperature (T-T)
  • -5 - 50 °C
  • Storage relative humidity (H-H)
  • 0 - 95%
  • Storage temperature (T-T)
  • -20 - 70 °C
  • Packaging data
  • Package depth
  • 555 mm
  • Package height
  • 101 mm
  • Package weight
  • 3.87 kg
  • Package width
  • 365 mm
  • Performance
  • Built-in processor
  • Y
  • Mean time between failures (MTBF)
  • 465240 h
  • Noise level
  • 45.9 dB
  • Virtual stacking (units)
  • 32
  • Ports & interfaces
  • Console port
  • RJ-45
  • Fiber optic connector
  • SFP+
  • SFP+ module slots quantity
  • 4
  • Switch Number of Ports
  • 48
  • Switch Port Speed
  • Gigabit Ethernet (10/100/1000)
  • Power
  • AC input frequency
  • 50 - 60 Hz
  • AC input voltage
  • 100 - 240 V
  • Power consumption (max)
  • 40.7 W
  • Redundant power supply (RPS) support
  • Y
  • Surge protection voltage
  • 6 kV
  • Power over Ethernet (PoE)
  • Power over Ethernet (PoE)
  • N
  • Security
  • Access Control List (ACL)
  • Y
  • Access Control List (ACL) rules
  • 1024
  • Authentication
  • Guest VLAN, MAC-based authentication, Port-based authentication, Web-based authentication
  • BPDU filtering/protection
  • Y
  • DHCP features
  • DHCP server,DHCP client
  • IGMP snooping
  • Y
  • IP-MAC-Port binding
  • Y
  • Security algorithms
  • 802.1x RADIUS,SNMP,SNMPv3,SSH,SSH-2,SSL/TLS
  • SSH/SSL support
  • Y
  • Technical details
  • Master (outer) cases per pallet (air)
  • 24 pc(s)
  • Master (outer) cases per pallet (sea)
  • 24 pc(s)
  • Pallet gross length
  • 110 cm
  • Pallet gross weight (air)
  • 318.3 kg
  • Pallet gross weight (sea)
  • 318.3 kg
  • Pallet gross width
  • 120 cm
  • Pallet height (air)
  • 173 cm
  • Pallet height (sea)
  • 173 cm
  • Products per pallet (air)
  • 72 pc(s)
  • Products per pallet (sea)
  • 72 pc(s)
  • Products per shipping (inner) case
  • 3 pc(s)
  • Shipping (inner) case gross weight
  • 12.5 kg
  • Shipping (inner) case height
  • 39.8 cm
  • Shipping (inner) case length
  • 57.3 cm
  • Shipping (inner) case net weight
  • 7.25 kg
  • Shipping (inner) case width
  • 32.4 cm
  • Weight & dimensions
  • Depth
  • 210 mm
  • Height
  • 44 mm
  • Weight
  • 2.4 kg
  • Width
  • 440 mm
